| Part Number | VMF-28 PM |
|---|---|
| Construction | 304 Stainless steel and carbon steel with corrosion resistant zinc oxide primed, dry powder epoxy coating |
| Hopper Capacity | 5.0 cu. ft. – custom sizes available |
| Feed Rate | 0.03 to 50.0 cu. ft. per hour |
| Accuracy | 2% of volume |
| Feed Screw | 0.75" to 3.25" diameter solid auger or 1.5" to 3.25" diameter open helix auger in 304 or 316 stainless steel – custom sizes available |
| Overwind Helix | 3.63" diameter - 304 or 316 stainless steel |
| Controls | Variable speed DC NEMA 4X, SCR motor control (SCADA programmable and HMI PLC touch screen controllers available) |
| Control Input | 4-20 mA |
| Motor Type | Right-angle geared, TENV 90 VDC, Washguard® motor 1/8 HP, 14 RPM; 1/4 HP, 42 RPM; or 1/2 HP, 83 RPM |
| Available Motors | Explosion proof - TENV 90 VDC 1/2 HP motor and gearing |
| Vibratory Agitator | Optional electric or pneumatic styles |
| Ambient Temperature Limit | 10°C - 40°C |
| Power | 115 VAC, 50-60 Hz, 4 Amps |
| Weight | Contact factory |
