Scaletron™ Sets The Standard
In Corrosion Resistance™
In Corrosion Resistance™
| Part Number | VMF-90WT |
|---|---|
| Construction | 304 Stainless steel - 316 stainless steel optional |
| Hopper Capacity | 1.5 cu. ft. – custom sizes available |
| Feed Rate | 0.07 to 60 cu. ft. per hour |
| Accuracy | 1% of volume |
| Feed Screw | 0.50", 0.75", 1.0", 1.5", 2.5" or 3.75" diameter solid auger in 304 or 316 stainless steel – custom sizes available |
| Overwind Helix | 304 or 316 stainless steel |
| Controls | Variable speed DC NEMA 4X, SCR motor control capable of remote installation (SCADA programmable and HMI PLC touch screen controllers available) |
| Control Input | 4-20 mA |
| Motor Type | Right-angle geared, TENV 90 VDC, Washguard® motor 1/2 HP, 83 RPM |
| Available Motors | Explosion proof - TENV 90 VDC 1/2 HP motor and gearing |
| Vibratory Agitator | Optional electric or pneumatic styles |
| Mixing Tank | Optional 35, 50 or 75 gallon with mixer motor and propeller |
| Wetting Cone | Optional high volume with 1.5" eductor |
| Ambient Temperature Limit | 10°C - 40°C |
| Power | 115/230 VAC, 50-60 Hz, 4 Amps |
| Weight | Contact factory |
